TYCLON

BNC-HV-R

$9.08
Tax included
You must register and log in to download
3D CAD Download
Contact us Contact us View Datasheet View Datasheet
If you would like the English version of the document,please contact us.
CAD data can also be created.

Description

The BNC-HV-R is an MHV Receptacle. This connector is suitable for various high-frequency applications.It features a impedance Mismatch, and has a rated voltage of AC 1600V, ensures a high insulation resistance (1000MΩ(Min.) at DC 500V), a low contact resistance (3 mΩ(Max.).The contact is made of Phosphor Bronze/Gold Plating, while the body is Brass/Nickel Plating.Terminal Shape is solder.We can customize our products for you. We offer total customization, including changes to a product's shape, length, material, surface treatment, and packaging.Available from 1 piece for in-stock items.

Specifications
  • Connector Gender
    Jack
  • Impedance (Ohms)
    Mismatch
  • Rated Voltage AC
    AC 1600V
  • Insulation Resistance
    1000MΩ(Min.) at DC 500V
  • Withstand Voltage
    AC 5000V(1 minute)
  • Contact Resistance
    3 mΩ(Max.)
  • Terminal Shape
    solder
