TYCLON

MC-4J

$3.92
Tax included
If you would like the English version of the document,please contact us. CAD data can also be created.
contact us
Contact us Contact us View Datasheet View Datasheet
If you would like the English version of the document,please contact us.
CAD data can also be created.

Description

The MC-4J is an MC Straight Jack connector. This connector is suitable for various high-frequency applications. It features a impedance Mismatch, and has a rated voltage of AC 125V, ensures a high insulation resistance (1000MΩ(Min.) at DC 500V), a low contact resistance (5 mΩ(Max.). The contact is made of Phosphor Bronze/Gold Plating, while the body is Zinc Die-Cast/Nickel Plating. We can customize our products for you. We offer total customization, including changes to a product's shape, length, material, surface treatment, and packaging. Available from 1 piece for in-stock items.

Specifications
  • Connector Gender
    Jack
  • Impedance (Ohms)
    Mismatch
  • Rated Voltage AC
    AC 125V
  • Insulation Resistance
    1000MΩ(Min.) at DC 500V
  • Withstand Voltage
    AC 1000V(1 minute)
  • Contact Resistance
    5 mΩ(Max.)

    • Safe & Secure

    We ensure secure processing of your payment information and do not retain or have any access to your credit card details.

    • American Express
    • Apple Pay
    • Google Pay
    • JCB
    • Mastercard
    • Shop Pay
    • Visa

Material/Plating/Attachment
  • Contact
    Phosphor Bronze/Gold Plating
  • Body
    Zinc Die-Cast/Nickel Plating

The MC-4J is an MC Straight Jack connector. This connector is suitable for various high-frequency applications. It features a impedance Mismatch, and has a rated voltage of AC 125V, ensures a high insulation resistance (1000MΩ(Min.) at DC 500V), a low contact resistance (5 mΩ(Max.). The contact is made of Phosphor Bronze/Gold Plating, while the body is Zinc Die-Cast/Nickel Plating. We can customize our products for you. We offer total customization, including changes to a product's shape, length, material, surface treatment, and packaging. Available from 1 piece for in-stock items.

Featured collection

RF Coaxial Connector MC Jack
TYCLON

MC-4J

$3.92

MC Jack

Cable type

N/A

Connector Gender

Jack

Impedance (Ohms)

Mismatch

Rated Voltage AC

AC 125V

Operating Frequency Range

N/A

Insulation Resistance

1000MΩ(Min.) at DC 500V

Withstand Voltage

AC 1000V(1 minute)

Contact Resistance

5 mΩ(Max.)

V.S.W.R

N/A

Operating Temperature Range

N/A

Crimping Tool

N/A

Rated Power (W)

N/A

Attenuation (dB)

N/A

Length (m)

N/A

Terminal Shape

N/A
