What are BNC Coaxial Cable Assemblies?

Summary

Tyclon offers a variety of coaxial BNC cables.
Seven cable stocks are available: RG-142B/U, RG-174/U, RG-316/U, RG-55/U, RG-55A/U, RG-58/U, RG-58A/U, RG-59/U, and RG-8/U.
By attaching various coaxial BNC connectors to them, we can manufacture to order from a single piece with any combination and length you specify.
After production, we conduct visual inspections in accordance with in-house regulations and also conduct 100% continuity tests.

Pre-processed BNC male to BNC male and RG-58A/U cables are also available in 6 products: 0.5m, 1m, 1.5m, 2m, 3m, and 5m.
These can be purchased immediately on the Tyclon website for quick delivery.

Request Your Custom Quote

BNC RG-174/U Cable Assemblies

BNC Plug to Plug Cable Using RG-174/U Coax

Small Lot Orders Available: BNC RG-174/U Cable

> BNC Plug to BNC Plug Cable
> BNC Plug to Open Cable

BNC RG-316/U Cable Assemblies

BNC plug to plug cable using RG-316/U coax

Small Lot Orders Available: BNC RG-316/U Cable

> BNC Plug to BNC Plug Cable
> BNC Plug to Open Cable

BNC RG-58A/U Cable Assemblies (In Stock)

Coaxial cables with RF connectors

Small Lot Orders Available: BNC Plug-to-Plug Cables: In Stock

> 0.5 m
> 1.0 m
> 1.5 m
> 2.0 m
> 3.0 m
> 5.0 m

BNC RG-8/U Cable Assemblies

BNC plug to plug cable using RG-8/U coax

Small Lot Orders Available: BNC RG-8/U Cable

> BNC Plug to BNC Plug Cable
> BNC Plug to Open Cable

BNC Coaxial Cable Assemblies FAQs

QWhat is a BNC coaxial cable assembly?
A

A BNC coaxial cable assembly is a pre-assembled cable featuring BNC (Bayonet Neill–Concelman) connectors on both ends, designed for transmitting radio frequency (RF) signals. These assemblies are essential for applications such as video signals (e.g., CCTV, broadcast), RF systems (e.g., antennas, test equipment), networking (e.g., 10base2 Ethernet), medical equipment, and aerospace/defense. Tyclon offers a range of options using various cable types, such as RG-174/U, RG-58A/U, and more.

QWhat cable types are available for Tyclon’s BNC cable assemblies?
A

Tyclon provides BNC cable assemblies in the following cable types:

  • RG-142B/U
  • RG-174/U
  • RG-316/U
  • RG-55/U
  • RG-55A/U
  • RG-58/U
  • RG-58A/U
  • RG-59/U
  • RG-8/U

These cater to diverse engineering needs, such as flexibility, frequency range, or specific application

QWhat are the standard lengths available for ready-made BNC cable assemblies?
A

For immediate purchase, Tyclon offers pre-processed RG-58A/U BNC male-to-male cable assemblies in the following lengths:

  • 0.5 meters
  • 1 meter
  • 1.5 meters
  • 2 meters
  • 3 meters
  • 5 meters

These are in stock and can be ordered directly from Tyclon’s website.

QCan I order custom lengths or configurations for BNC cable assemblies?
A

Yes, Tyclon offers total customization, allowing engineers to specify:

  • Custom lengths
  • Different cable types
  • Alternative connector configurations

There is no minimum order quantity, making it ideal for prototypes, small projects, or unique requirements

QWhat is the impedance of Tyclon’s BNC cable assemblies?
A

The impedance depends on the cable type:

  • 50Ω: Common for RF applications (e.g., RG-58A/U, RG-174/U, RG-316/U, RG-8/U)

For exact impedance details or information on other cable types, please contact Tyclon or consult our catalog.

QWhat materials are used in the connectors for Tyclon’s BNC cable assemblies?
A

The connectors feature:

  • Brass: For durability
  • Gold plating: On contacts for enhanced conductivity
  • Nickel plating: On the body for corrosion resistance

These ensure reliable performance in demanding environments.

QWhat quality control measures does Tyclon implement?
A

Tyclon ensures reliability through:

  • Visual inspections: Per in-house regulations to detect physical defects
  • 100% continuity tests: To verify electrical performance

This rigorous process guarantees high standards for critical applications.

QHow can I access detailed specifications for Tyclon’s BNC cable assemblies?
A

Detailed specs are not publicly listed. Engineers can:

  • Register for Tyclon’s catalog at Catalog Registration
  • Contact Tyclon’s sales team for specific inquiries

QWhat applications are Tyclon’s BNC cable assemblies suitable for?
A

These assemblies are versatile, supporting:

  • RF systems: Antennas, test equipment
  • Networking: 10base2 Ethernet
  • Medical equipment: Reliable signal transmission
  • Aerospace and defense: Durable, high-performance needs

Compatibility with other BNC systems depends on matching impedance and frequency requirements.

QWhy choose Tyclon’s BNC cable assemblies?
A

Tyclon stands out with:

  • A wide range of cable types and configurations
  • Options for both ready-made and fully custom orders
  • No minimum order quantity
  • Rigorous quality control (visual inspections and continuity tests)
  • Support for small-scale and prototype projects
    This combination makes Tyclon a reliable partner for engineers across industries.

QIs there a minimum order quantity for custom BNC cable assemblies?
A

No, Tyclon accepts single-piece orders, offering flexibility for small-scale or prototype projects.

QWhat are the lead times for ready-made and custom orders?
A
  • Ready-made assemblies: Available for immediate purchase with quick delivery.
  • Custom orders: Lead times vary and should be confirmed with Tyclon directly.

QHow can I order BNC coaxial cable assemblies, and what support do you offer?
A

Ordering is simple—you can purchase our BNC coaxial cable assemblies directly on our website or contact our sales team for assistance via our Inquiry Form.
